CKAD field manual

k8s Gateway API YAML example

Ingress mixes listener and routing. Gateway API splits them. The GatewayClass must already exist.

All traffic passes a single sky arch; an officer watches from a balcony. All traffic passes a single sky arch; an officer watches from a balcony.
Gateway
apiVersion: gateway.networking.k8s.io/v1
kind: Gateway
metadata:
  name: web
  namespace: app
spec:
  gatewayClassName: nginx
  listeners:
    - name: http
      protocol: HTTP
      port: 80
      allowedRoutes:
        namespaces:
          from: Same
HTTPRoute
apiVersion: gateway.networking.k8s.io/v1
kind: HTTPRoute
metadata:
  name: web
  namespace: app
spec:
  parentRefs:
    - name: web
  hostnames:
    - web.example
  rules:
    - matches:
        - path:
            type: PathPrefix
            value: /
      backendRefs:
        - name: web
          port: 80

Fields

gatewayClassName
Picks the controller. Same idea as ingressClassName. No class → nothing listens.
parentRefs
Which Gateway this route attaches to. name, optional namespace and sectionName.
backendRefs
The Service. port is required. weight is for a canary split.
PathPrefix
type: PathPrefix, value: /api. Not pathType — that is Ingress.
allowedRoutes
from: Same is the usual exam answer. All lets other namespaces attach.

Watch

  • apiVersion is gateway.networking.k8s.io/v1. Not networking.k8s.io — that is Ingress.
  • HTTPRoute uses type: PathPrefix, not pathType. backendRefs[].port is required.
  • The GatewayClass must exist. allowedRoutes.from: Same unless the question says otherwise.
